2 Approaches – 1 Goal: Simpler and faster Sealing
1. Feeler Gage and Sealing Gap
The solution for the expert:
The feeler gage gives you the true picture. REINZOPLAST is the only right choice for gaps up to 0.14 mm between the surfaces to be sealed.
Seal larger gaps (from 0.15 mm) quickly and reliably with REINZOSIL.
REINZOSIL
Sealing gap present (≥ 0.15 mm)
Deep scratches and scoring/cracks in components
REINZOSIL-t
Visible sealing joint
REINZOPLAST
No sealing gap present (< 0.14 mm)
Product Characteristics
Choose the right sealant based on temperature, media resistance or drying time.
All detailed technical properties of REINZOSIL, REINZOSIL-t and REINZOPLAST are listed in our table:
Technical data
Packing unit
Tube 70 ml:
70-31414-10
Aerosol can 200 ml:
70-31414-20
Cartridge 310 ml:
70-31414-40
Tube 70 ml:
70-31453-00
Tube 80 ml:
70-24571-10
Cartridge 300 ml:
70-24575-20
Sealing gap
≥ 0.15 mm
≥ 0.15 mm
≤ 0.15 mm
Temperature
peak temperature (short duration) [°C]
continuous temperature [°C]
320
-50 to 250
200
-50 to 180
300
-50 to 250
Media resistance incl. biofuels
++
++
++
Dosing properties
Tube: +
Aerosol can: ++
Cartridge: ++
Tube: +
Tube: ++
Cartridge: ++
Skinning time
10 - 15 min.
10 - 15 min.
none
Curing
quickly curing, permanently elastic, non-setting, permanently plastic
++
Easy removal
++
Sealing without disassembly
++
++
Technical data
Packing unit
Tube 70 ml:
70-31414-10
Aerosol can 200 ml:
70-31414-20
Cartridge 310 ml:
70-31414-40
sealing gap
≥ 0.15 mm
Temperature
peak temperature (short duration) [°C]
continuous temperature [°C]
320
-50 to 250
Media resistance incl. biofuels
++
Dosing properties
Tube: +
Aerosol can: ++
Cartridge: ++
Skinning time
10 - 15 min.
Curing
quickly curing, permanently elastic, non-setting, permanently plastic
++
Easy removal
Sealing without disassembly
++
Technical data
Packing unit
Tube 70 ml:
70-31453-00
Sealing gap
≥ 0.15 mm
Temperature
peak temperature (short duration) [°C]
continuous temperature [°C]
200
-50 to 180
Media resistance incl. biofuels
++
Dosing properties
Tube: +
Skinning time
10 - 15 min.
Curing
quickly curing, permanently elastic, non-setting, permanently plastic
Easy removal
Sealing without disassembly
++
Technical data
Packing unit
Tube 80 ml:
70-24571-20
Cartridge 300 ml:
70-24575-20
sealing gap
≤ 0.15 mm
Temperature
peak temperature (short duration) [°C]
continuous temperature [°C]
300
-50 to 250
Media resistance incl. biofuels
++
Dosing properties
Tube: ++
Cartridge: ++
Skinning time
none
Curing
quickly curing, permanently elastic, non-setting, permanently plastic
Easy removal
++
Sealing without disassembly
REINZOSIL
Quick-hardening Silicone Sealant
REINZOSIL is especially ideal for sealing surfaces in engines, transmission, axles, cylinder liners and plastic housings
It is very suitable for rough sealing surfaces and can be used universally for all motor and vehicle makes.
REINZOSIL is resistant to gasoline and diesel fuels, biodiesel, oils, greases, lubricants, water, seawater, sunlight and ozone.
There is no outgassing, i.e. no gas escapes from REINZOSIL highly elastic universal sealing compound under the effects of temperature, so it does not influence electronic sensors.
Excellent positioning
Homogeneous sealing bead
High-temperature resistance from -50 °C to +320 °C (short-term peak temperature)
Low-odor
Can be processed on vertical and overhead surfaces
For sealing two-dimensional connections with sealing gap ≥ 0.15 mm (even without parts disassembly)
Prevents corrosion of sealing surfaces
No marking required
Sensor Safe (ideal sealant for many housing components which cover sensitive electronics)
REINZOSIL-t
The transparent Solution from REINZOSIL
REINZOSIL-t is the transparent version of REINZOSIL and is especially ideal for sealing surfaces with visible sealing joints.
REINZOSIL-t is resistant to gasoline and diesel fuels, biodiesel, oils, greases, lubricants, water, seawater, sunlight and ozone.
High-temperature resistance from -50 °C to +200 °C (short-term peak temperature).
Excellent positioning
Transparent, homogeneous sealing bead
High-temperature resistance from -50 °C to +200 °C (short-term peak temperature)
Low-odor
Can be processed on vertical and overhead surfaces
For sealing two-dimensional connections with sealing gap ≥ 0.15 mm (even without parts disassembly)
Prevents corrosion of sealing surfaces
No marking required
REINZOPLAST
Unique permanently plastic wet Sealing
REINZOPLAST is a permanently plastic, non-hardening PU sealing compound and is resistant to gasoline and diesel fuels, biodiesel, oils, greases, lubricants, water, seawater, sunlight and ozone.
High-temperature resistance from -50 °C to +300 °C (short-term peak temperature).
REINZOPLAST has excellent flow properties and does not crack when exposed to vibration.
Excellent flow properties
Immediate assembly possible
High-temperature resistance from -50 °C to +300 °C (short-term peak temperature)
Odorless
Immediately withstanding full load
Permanently plastic wet sealing
Non-hardening polyurethane sealing compound for demanding sealing joints without sealing gap, e.g. with vibration
No marking required
RE-MOVE
Removes Sealants in Seconds
Just follow these instructions:
Cover any oil and coolant channels, as well as bearing surfaces.
Shake can well before use.
Spray onto the sealing surfaces until a closed film develops, and allow to react for approx. 10 minutes.
Remove residues with a brush or spatula (Attention: Do not damage the sealing surfaces!)
Thoroughly clean the sealing surfaces with a dry, lint-free cloth.
Turn the can upside down after use, and press button to clear the nozzle.
For the removal of seals, sealing residues, sealing compounds, resin and varnish residues
Adheres firmly and does not drip
Economic use
Highly effective
Can be used on inclined and vertical surfaces
Ether-based solvent
No damage to sealing surfaces
Just seal it!
You can find all information about liquid sealants and gasket removers in our brochure.
